Mold Care
Care for the mould. Ready for the next run.
- Model range
- MMS 150 / 300 / 450
- Linear-guided platen
- 360° rotating top platens
- T-slot mould holding brackets
- Extension table and mould carrier
- Height-adjustable extension table
MMS 150 — Rear view
06 See it run
Mould maintenance station
Mould separation, platen rotation and the mobile extension table, demonstrated in the original Mold Care product film.
Technical overview
Mould handling, engineered.
A dedicated station for mould maintenance and assembly. A linear-guided platen separates the mould halves, the top platens rotate through 360° for full access, and mechanical brackets on T-slots hold the mould securely throughout servicing. Available in MMS 150, MMS 300 and MMS 450.
- Linear-guided platenLinear motion guides separate the two mould halves smoothly and in alignment.
- 360° rotating top platensTop platens rotate through 360° for access to every face of the mould.
- T-slot mould clampingMechanical brackets slide along T-slots to secure moulds of varying size.
- Mobile extension tableHeight-adjustable extension table on castor wheels doubles as mould carrier and workbench.
Models: MMS 150, MMS 300 and MMS 450. Images and 360° view show MMS 150. Confirm dimensions, load capacity and configuration at enquiry.
